20
Speedometer System Set-up
The speedometer system set-up allows users to con-
figure engine information output from the speedome-
ter and adjust different display options to suit user
needs.
Viewing the speedometer system set-up — From
the speedometer Main Menu, use the UP / DOWN
buttons to scroll through the LCD screens until the
System Set-up screen appears. Press ENTER. Use
the UP / DOWN buttons to view the set-up features.
Press ENTER to access each feature.
The system set-up controls the following:
• LCD Contrast
• Speed Units
• Display Units
¾
LCD Contrast
The display contrast of the speedometer can be adjusted to aid in viewing
LCD screens in different lighting conditions.
Setting LCD Contrast — From the System Set-Up screen, scroll to the
Set-Up Contrast display. Press ENTER. “SET” appears in the upper right
corner of the LCD screen. Using the UP / DOWN buttons, select a contrast
value and press ENTER to set the display.
Contrast settings have a range of ten (1 to 10).
NOTE: Only values 3 to 7 can be stored in memory and retained on subse-
quent power ups.
Adjusting backlighting — Speedometer gauge backlighting is set by the
tachometer gauge. (To adjust the backlighting, see “Instrument Backlighting”
on page 12.)
System Set-Up Menu
To Next Page
