Moving Beam 7R User’s Manual Ver. 1.00 Page24
o DMX Mode
Each device can be individually controlled using a standard DMX-512 controller.
You must "address" each device through the "A001" menu. The filled-in address is then the base
address, address from which the device will respond.
If two devices are addressed to the same DMX address; they will then behave identically, responding
to the same DMX channels.
Wired DMX mode :
Press the MENU key and then DOWN to access the next menu. Then press ENTER then DOWN to reach
the Signal Set menu. Press ENTER and then check the DMX Cable box. Confirm this choice by pressing
ENTER.
Press the MENU key and then UP to go to the first menu. Press ENTER to select the Dmx Address menu.
Use the UP & DOWN keys to select the DMX address of the device. Press ENTER to confirm your choice.
Finally, press MENU 2 times to return to the main menu. The unit is in DMX mode, and if no DMX signal
is present, the display flashes. Then connect a DMX cable as input.
DMX mode selection via W-DMX (wireless):
In the Signal Set menu, check the WDMX & CAB box. This mode activates the W-DMX receiver. When
the devices communicate with each other, the transmitting device flashes red and the receiver (s)
flashes green.
The LED is off: no connection.
The LED flashes green quickly: the connection to the transmitter has been lost.
The LED flashes green slowly: The connection to the transmitter is established, but there is no DMX
signal.
The LED is fixed green: The connection and the DMX signal are effective.
o DMX Protocol
