Moving Beam 7R User’s Manual Ver. 1.00 Page25
5
5
65..69
Color 6 + Color 7
70..74
Color 7
75..79
Color 7 + Color 8
80..84
Color 8
85..89
Color 8 + Color 9
90..94
Color 9
95..99
Color 9 + Color 10
100..104
Color 10
105..109
Color 10 + Color 11
110..114
Color 11
115..127
Color 11 + white
128.. 189
Forwards rainbow effect from fast to slow
190-193
Color rotation stop
194..255
Backwards rainbow effect from slow to fast
6
6
Gobo wheel 1
0..4
Open
5..9
gobo 1
10..14
gobo 2
15..19
gobo 3
20..24
gobo 4
25..29
gobo 5
30..34
gobo 6
35..39
gobo 7
40..44
gobo 8
45..49
gobo 9
50..54
gobo 10
55..59
gobo 11
60..64
gobo 12
65..69
gobo 13
70..74
gobo 14
75..79
gobo 15
80..84
gobo 16
85..92
Gobo 1 shake slow to fast
93..100
Gobo 2 shake slow to fast
101..107
Gobo 3 shake slow to fast
108..116
Gobo 4 shake slow to fast
117..124
Gobo 5 shake slow to fast
125..132
Gobo 6 shake slow to fast
133..140
Gobo 7 shake slow to fast
141..148
Gobo 8 shake slow to fast
149..156
Gobo 9 shake slow to fast
157..164
Gobo 10 shake slow to fast
165..172
Gobo 11 shake slow to fast
173..180
Gobo 12 shake slow to fast
181..188
Gobo 13 shake slow to fast
189..196
Gobo 14 shake slow to fast
197..204
Gobo 15 shake slow to fast
205..212
Gobo 16 shake slow to fast
213..255
Rot. gobo wheel cont. rotation slow to fast
7
7
Shutter
0..31
Shutter closed
32..63
shutter open
64..95
Strobe effect slow to fast
96..127
shutter open
128..143
Opening pulse in sequences slow to fast
144..159
Closing pulse in sequences fast to slow
160..191
shutter open
192..223
Random strobe effect slow to fast
224..255
shutter open
8
8
Dimmer
0..255
Dimmer 0%...100%
9
9
Focus
0..255
In(near) to Out(far)
