Moving Beam 7R User’s Manual Ver. 1.00 Page26
10
10
Rrotating prism1
0..5
Prism1 swing out(hole)
6..127
Prism1 swing in
128..189
Prism1 Forwards rotation from fast to slow
190..193
Prism1 rotation stop
194..255
Prism1 Backwards rotation from slow to fast
11
11
Rrotating prism2
0..5
Prism2 swing out(hole)
6..127
Prism2 swing in
128..189
Prism2 Forwards rotation from fast to slow
190..193
Prism2 rotation stop
194..255
Prism2 Backwards rotation from slow to fast
12
12
Frost
0..199
Frost swing out
200..255
Frost swing in
13
13
Speed pan/tile
0..225
max to min speed
226..235
blackout by movement
236..245
blackout by all wheel changing
246..255
no function
14
14
Special function
0..19
No function
20..29
No function
30..39
No function
40..59
Lamp on
60-79
Lamp switch off
80..84
Total Reset
85..87
Pan/Tilt Reset
88..90
Color Reset
91..93
Gobo Reset
94..96
Strobe Reset
97..99
The Others Reset
100..119
Internal program 1
120..139
Internal program 2
140..159
Internal program 3
160..179
Internal program 4
180..199
Internal program 5
200..219
Internal program 6
220..239
Internal program 7
240..255
Internal program 8
1 5
Color Time
0..255
max to min speed
1 6
Gobo Time
0..255
max to min speed
