12
POND
POND
Return direct
to pond or via a
waterfall / blade
TEMPEST FILTER INSTALLATION IDEAS
TYPICAL STANDALONE TEMPEST FILTER INSTALLATIONS
Install a Tempest Filter on a quarantine system, or a standalone pond up to 5,000
litres, at the side of a pond or above the pond. The slide valves on the Tempest
Filter enable connection to 1½" pressure pipe. If installing the Tempest Filter using
flexible hose you will need to fit a reducing sleeve (EA Code: M35-050) and a
1½" solvent stepped hosetail (EA Code: HOSETAIL15) inside each slide valve.
OPTIMUM
FLOW RATE:
5,000 LPH
1,100 GPH
1,320 US GPH
IMPORTANT: Ensure slide valves are fitted to inlet and outlet of
the Tempest filter.
IMPORTANT: We always recommend fitting unions when installing in
line equipment on your system which help when removing the filter.
