Evolution RAGE7-S User Manual

13
www.evolutionpowertools.com
EN
DE
Fig 5
Close up view of battery
compartment cover
and xing screw.
5. LASER CUTTING GUIDE
This jigsaw is tted with a Laser Guide which can be useful when
cutting straight lines. Only switch the Laser Guide on when you
are about to make a straight cut, and switch it o when the cut
has been completed. The switch is located on the front of the
machine. Press the ‘I’ side of the rocker switch to turn the Laser
Guide ‘On’. Press the ‘O’ side of the rocker switch to turn the
Laser Guide ‘O’.
WARNING: Do not stare directly at the laser beam. A hazard
may exist if you deliberately stare into the beam. Please observe
all of the following safety rules.
• Thelaserbeammustnotbedeliberatelyaimedatpersonnel
and must be prevented from being directed towards the eyes
of a person or animal.
• Alwaysensurethatthelaserbeamisusedonlyonworkpieces
that have non-reective surfaces, i.e natural wood or matt
surfaces etc.
• Neverexchangethelasermoduleassemblyforadierent
type or class of laser.
• Repairstothelasermodulemustonlybeconductedby
Evolution Power Tools or their authorized agent.
REPLACEMENT OF LASER BATTERIES
Power for the Laser Guide is provided by two (2) ‘AAA’ Cells.
When exhausted these should be replaced.
Access to the battery compartment is gained by loosening the
screw and removing the battery compartment cover.
(Fig. 5)
Observe the polarity of the cells and replace the cover after cell
replacement.
6. FOOTPLATE ANGLE ADJUSTMENT
Note: The footplate is factory set and adjusted so that the blade
cuts at 90
0
to the footplate.
The footplate may be tilted to an angle of up to 45
0
to either
side with positive location stops at 15
0
, 30
0
and 45
0
.
To adjust the footplate:
WARNING: Disconnect the jigsaw from the power supply before
attempting to adjust the footplate.
• Uncliptheplasticfootplateshoeandstoresafelyforfuture
installation. (Fig. 6)
• WithdrawtheDustExtractionAdaptortube,iftted,and
store safely for future installation. (Fig. 7)
Fig 6
View of footplate shoe
being unclipped and
removed from footplate.
Fig 7
View of Adaptor tube in
service position.
