Evolution S210 - Page 3

3
www.evolutionpowertools.com
EN
MACHINE SPECIFICATIONS UK/EU USA
Motor UK/EU (220-240V ~ 50 Hz) 1800W -
Motor UK (110V ~ 50 Hz) 1600W -
Motor USA (120V ~ 60 Hz) - 15A
No Load Speed (min
-1
/rpm) 2800
Gross weight 11.2kg 24.7lbs
Net weight 8.9kg 19.6lbs
Power cable length 3M 10ft
CUTTING CAPACITIES UK/EU USA
Max steel box section/pipe 90° 76.2mm 3”
Max Thickness (Plate) 13mm 0-1/2”
Max Wall Thickness 6mm 0-7/32”
Track cutting capacity 72mm 2-26/32”
BLADE SPECIFICATIONS UK/EU USA
Blade Diameter 210mm 8-1/4”
Max. Speed (min
-1
/rpm) 3750 3750
Bore Diameter 25.4mm 1”
Kerf 2mm 5/64”
Teeth 50
SPECIFICATIONS
NOISE & VIBRATION DATA
Sound pressure level L
pA
(220-240V) 94.2dB
Sound power level L
WA
(220-240V) 105.2dB
Vibration (220-240V) a
h
=2.84 (main handle)
a
h
=3.35(auxiliary handle)
Sound pressure level L
pA
(110V) 92dB
Sound power level L
WA
(110V) 103dB
Vibration (110V) a
h
=3.03(main handle)
a
h
=3.57(auxiliary handle)
WARNING: Due to the power input of this product on start up, voltage drops may occur and
this can influence other equipment (e.g. dimming lights). So for technical reasons we advise, if
the mains-impedance is Zsysmax< 0.2626 , these disturbances are not expected. If you require
further clarification, you may contact your local power supply authority.
