14
www.evolutionpowertools.com
S355CPS / S380CPS MACHINE OVERVIEW
1. LOWER BLADE GUARD
2. UPPER BLADE GUARD
3. QUICK RELEASE MECHANISM
4. FRONT SWIVELLING VICE JAW
5. REPOSITIONABLE REAR VICE JAW
6. CUTTING HANDLE
7. CUTTING HEAD HOLD DOWN PIN
8. REAR VICE JAW LOCKING LEVER
9. TRAVEL STOP ADJUSTMENT SCREW
10. PROTRACTOR SCALE
11. WORK BENCH MOUNTING HOLES X4
12. BLADE CHANGE HEX KEY
13. BLADE ARBOR GUARD
14. ARBOR LOCK BUTTON
15. POSITIVE STOP LOCATION PIN
16. SHIELD
17. VICE HANDLE
18. CARBON BRUSHES ACCESS CAP
19. ON/OFF TRIGGER SWITCH
20. CARRY HANDLE
21. CHIP COLLECTION TRAY
6
2
1
3
17
5
7
8
10
11
13
16
4
18
19
20
21
9
12
14
15
