IONPURE
®
LX CEDI Modules
Page 7 IP-MAN-LX-1220-EN.pdf
1. INTRODUCTION
1.1. LX Product Family Overview
Ionpure LX modules are medium flow rate CEDI devices. Their compact state-of-the-art
design assures ease of installation, maintenance, and service. LX modules are available
in the following sizes:
Size Nominal Flow Description
IP-LXM04 2.0 gpm (0.45 m
3
/h) 4-cell
IP-LXM10 5.0 gpm (1.14 m
3
/h) 10-cell
IP-LXM18 9.0 gpm (2.05 m
3
/h) 18-cell
IP-LXM24 12.5 gpm (2.84 m
3
/h) 24-cell
IP-LXM30 15.0 gpm (3.4 m
3
/h) 30-cell
IP-LXM45 22.5 gpm (5.1 m
3
/h) 45-cell
For more information on the LX module specifications and flow rates, see Section 2.4 and
Appendix A of this Manual.
There are four different types of LX modules (see Appendix D), each of which is available
in the six sizes listed above:
EU-4 For European Pharmacopeia (EP) applications
HI-3 For U.S. Pharmacopeia (USP) applications, hot water sanitizable (HWS)
X-4 For USP, NSF (drinking water) and general use (worldwide) applications
Z-5 For General Industry, with improved Cl
2
tolerance
Figure 1-1: LX Module (Cathode/Plumbing Side Shown)
HI type (BSP Female) EU / X / Z type (BSP Male)
