EVS XT-3 Technical Reference Hardware Manual

XT3 Series DISK RECORDER - Version 10.05 - Hardware Technical Reference Manual
Issue
10.05.D
EVS Broadcast Equipment SA – July 2011
67
3.3 AUDIO CODEC BOARD
The AUDIO CODEC board is the audio interface between the V3X boards and the
H3X board. VIDEO CODEC and AUDIO CODEC boards are tied to the H3X board
with one Bus connector on the front side. Different audio configurations are
available with the AUDIO CODEC board. See section 2.6 ‘Audio Configurations’,
on page 40 for details.
LED INFORMATION AND CONNECTOR
LD 1-3: Internal EVS information only
LD4: transfer activity to/from the H3X board
AES/EBU
ANALOG
