Machine
description – quick overview
Right side
18
099-008060-EW501
19.02.2013
Item
Symbol
Description 0
1
Carrying handle
2
Machine „ON/OFF“ control lamp
3
Main switch, machine on/off
4
Welding machine mains connection socket – 400 V CEE
Protected by the fuses in the calibration device (20 A)
5
„Input“ welding current socket
Connection to welding machine, socket „+“
6
Machine feet
7
„Input“ welding current socket
Connection to welding machine, socket „-“
8
Welding machine mains socket – 32 A 400V CEE
Protected by mains fuse of calibration device
9
Welding machine mains connection socket - 230 V CEE 7/4
Protected by the fuses in the calibration device (20 A)
10
Voltage measuring connection sockets (External)
Connection of the separate measuring leads to the external voltage measurement on
the welding machine’s welding current connections.
The voltage measuring point changeover switch has to be set to the External position.
