7 Technical data
NOTE
Performance specifications and guarantee only in connection with original spare and
replacement parts!
7.1 Calibration device (KLE)
Mains voltage
3 x 400 V (at 50/60Hz)
Mains fuse protection (safety fuse - slow-blow)
3 x 35 A
Max. connection load at 60% duty cycle
600 A
Max. connection load at 100% duty cycle
500 A
Load cycle
10 min
Ambient temperature
0 °C - +30 °C
Machine cooling
Fan
Protection classification
IP 23
Dimensions (L/W/H)
625 mm / 300 mm / 535 mm
Weight without accessories
25 Kg
Tolerance of display instruments
Current I
actual
Voltage U
actual
Wire feed speed WF
actual
0.4% of scale end value 500 A
1.0% of scale end value 100 V
0.4% of scale end value 25.0 m/min
EMC class
A
Constructed to standards
IEC 60974-1, -10
IEC 60664-1
/
7.2 Load simulation unit (LS 600 A)
Max. connection current load at 10% duty cycle
600 A
Max. connection current load at 100% duty
cycle
300 A
Max. connection voltage
120 V DC
50 V AC
Mains fuse (slow-blow safety fuse)
3 x 35 A
Load cycle
10 min
Mains voltage
3 x 400 V (at 50/60Hz)
Ambient temperature
0 °C - +30 °C
Machine cooling
Fan
Protection classification
IP 23
Dimensions L/W/H
1110 mm / 550 mm / 890 mm
Weight without accessories
139.5 Kg
EMC class
A
Constructed to standards
IEC 60974-1, -10
IEC 60664-1
/
