5. Connector panel and control possibilities
GhosT-OLED Full Kit, Half Kit and PCAP can be controlled via LAN or RS 232. As both versions
share the same LG Signage Box the information provided by the original “LG 55EW5F-A
Owner’s Manual”, and “LG 55EWF-A User Guide” as well as the original LG LAN control
manual can be applied to all GhosT-OLED products. The manuals are stored on the USB stick
that is included in every delivery.
Subsequently, the most important information are provided:
GhosT-OLED interfaces
Qty
Interface
usage
2
USB IN
Playing content via USB stick (maybe no Touch*
1
)
1
TOUCH USB (only at PCAP version)
PCAP Touch sensor connection
1
HDMI IN
Video Input
1
DP IN
Video Input
1
DP out
Daisy chaining DP signal
1
LAN IN
Controlling / monitoring
1
LAN out
Daisy chaining LAN signal
1
IR IN
External IR receiver
1
RS232C IN (3,5mm Jack)
Controlling / monitoring
1
RS232C out (3,5mm Jack)
Daisy Chaining RS232 signal
1
AUDIO out
Connecting to external speaker
1
LC out
Daisy chaining LC signal *
2
1
LC IN
Daisy chaining LC signal *
2
*
1
for using GhosT-OLED Touch Kit a PC is necessary (USB A connector) refer to chapter
4.4 Set up GhosT-OLED Touch Kit. For GhosT-OLED PCAP a PC is recommended but
controlling the OSD is possible by connecting the TOUCH USB port with USB IN port.
*
2
In video wall installations it’s necessary to connect the units with the LC cables
(Luminance Compensation). Refer to original LG 55EW5F-A Owner’s Manual, the
User Guide and the Quick set-up guide for detailed information regarding these
connections.
Note: The Full Kit version offers a modified LC connection via RJ45 CAT Cables, see
Figure 11 (the function of this interface is not affected by the modification).
