Copyright © 2017 MAT Industries, LLC
7 - ENG
ASSEMBLY INSTRUCTIONS
• SAVE ALL INSTRUCTIONS
1. Place the unit on its back and insert wheel
axle into front tube. Use (1) M6 washer and
(1) M6 x 15mm long hex head screw to
assemble wheel axle to frame using the
supplied open-end wrench. Tighten securely.
Repeat for opposite side.
2. Remove (1) M8 washer and (1) M8 nut from
wheel axle and place wheel onto axle.
Be sure the hub on the wheel goes to the
inside. Re-assemble the washer and nut
onto axle using the supplied open-end
wrench. Tighten securely. Repeat for
opposite side.
3. With the unit still on its back, assemble the
rubber feet using (1) M8 x 30mm long
socket head cap screw and (1) M8 nut.
Using the supplied hex wrench and open-
end wrench, tighten securely. Repeat for
opposite side.
4. Place the unit on its wheels and rubber feet.
Remove the knobs and screws from the
handle.
