Exerpeutic Elliptical - Rear Stabilizer Installation

2. Rear Stabilizer Installation.
Lift up the Main Frame (1) towards the end, and then align the Rear Stabilizer (3) onto the
rear curve of the Main Frame (1). Attach Two Carriage Bolts (34) and on the other ends
of bolts with two Washers (36) and two Cap Nuts (35). Hold the Rear Stabilizer (3) to the
Main Frame (1) and use the Multi Hex Tool with Phillips Screwdriver to tighten the Cap
Nuts (35) until firm and secure.
Hardware:
.
ASSEMBLY
11
(#36) Washer
2 PCS
(#34) Carriage Bolt
2 PCS
(#35) Cap Nut M8
2 PCS
Tool:
Multi Hex Tool with Phillips
Screwdriver
