7
No.
Description Qty
No. Description Qty
1 Rear Frame 1
36 Washer Ø6.2 2
2 Front Frame 1
37 Sensor with Wire 1
3 Rear Stabilizer 1
38 Flywheel Ø195 1
4 Handlebar 1
39 Belt Wheel with Crank Axle Ø155 1
5 Seat Post 1
40 Bearing Bracket 2
6 Seat 1
41 Wave Washer 1
7 Left Pedal 1
42 Bearing 6003RS 4
7-1
Left Pedal Strap 1
43 C-ring Ø17 6
8 Right Pedal 1
44 Belt Wheel with Crank Axle Ø150 1
8-1
Right Pedal Strap 1
45 Bearing 6000z 2
9 Backrest Frame 1
46 Axle Ø12.8x94L 1
10 Wire Plug 2
47 Eyebolt M6 2
11 Rear Stabilizer End Cap 2
48 Tension Bracket 2
12 Seat Post Plastic Bushing 1
49 Backrest 1
13 Tension Control Knob 1
50 Nylon Nut M6 2
14
Seat Adjustment Knob M16
1
51 Nut M10 2
15 Rear Supporting Tube 1
52 Washer Ø10.2xØ25 1
16 Oval Wire Plug 5
53 Wave Washer Ø17 1
17 Handrail Foam Grip 2
54 Idle Wheel Axle 1
18 Left Cover 1
55 Nylon Nut M10 1
19 Right Cover 1
56 Bearing 6902Z 2
20 Top Shroud 1
57 Axle 1
21 Round Plastic Bushing 6
58 Hexagon Socket Bolt M8*15 5
22 Safety Pin Ø10*110L 1
59 Rubber Cushion 1
23 Left Crank 1
60 Washer Ø8.2x Ø25x2.0t 2
24 Right Crank 1
61 Flat Phillips Head Screw M6x10 6
25 Flange Nut 2
62 Holder 1
26 Crank Cover 2
63
Round Phillips Head Screw
M4x10
1
27
Round Phillips Head Drilling
Screw M4x20
4
64 Plastic Washer 1
28
Round Phillips Head Tapping
Screw M4x20
5
65 C-ring Ø15 1
29 Hexagon Cap Nut M8 5
66 Square end cap 4
30 Curve Washer D Ø8.2 6
67 Rear Frame Support Tube 1
31 Front Stabilizer 1
68 Screw M5x20 1
32 C-ring Ø 10 2
69 Washer Ø5.2xØ18 2
33 Flat Washer Ø8.2 13
70 Spring 1
34 Nylon Nut M8 6
71 Belt 240J4 1
35 Magnet Bracket 1
72 Belt 230J3 1
To Next Page
