Maintenance
1.1 Torque values
Note: For unspecified bolts and nuts listed, refer to the table of standard torque values.
No.
Process Description
Bolt Specification
Torque Range
1
Oil Drain Plug Assy.
Oil Drain Plug
20 Ft. Lbs.
26 N.m
2
Spark Plug
M14×1
21 Ft. Lbs.
28 N.m
3
Connecting Rod Cover
Hex Flange Bolt M6×35
9 Ft. Lbs.
12 N.m
4
Crankcase Cover Bolt
Hex Flange Bolt M8×55
21 Ft. Lbs.
28 N.m
5
Fuel Pump Assy.
Hex Flange Bolt M6×16
5 Ft. Lbs.
7 N.m
6
Breather Valve Assy.
Hex Flange Bolt M6×12
8 Ft. Lbs.
10 N.m
7
Cylinder Head
Hex Flange Bolt M10×1.25×70
38 Ft. Lbs.
52 N.m
Hex Flange Bolt M10×1.25×50
8
Push Rod Location Limit Plate
Valve Adjust Stud
22 Ft. Lbs.
30 N.m
9
Valve Lash Inspection（Q1）
Valve Lock Nut M6
10 Ft. Lbs.
14 N.m
10
Valve Cover
Hex Flange Bolt M6×25
8 Ft. Lbs.
10 N.m
11
Flywheel
Hex Flange Bolt M12×35
62 Ft. lbs.
82 N.m
12
Ignition Coil
Hex Flange Bolt M6×20
8 Ft. Lbs.
10 N.m
13
Electric Starter Motor
Hex Flange Bolt M8×80
20 Ft. Lbs.
26 N.m
14
Inlet Pipe
Hex Flange Bolt M6×35
8 Ft. lbs.
10 N.m
Stud Bolt M6×106
5 Ft. Lbs.
7 N.m
15
Air Box
Nut, Flange M6
6 Ft. Lbs.
8 N.m
16
Cooling Fan
Hex Flange Nut M8×20
15 Ft. Lbs.
22 N.m
17
Cooling Fan Cover
Hex Flange Nut M5×16
3 Ft. lbs.
4 N.m
18
Fan Shroud
Hex Flange Step Bolt 6×21.8-8×10.8
6 Ft. Lbs.
8 N.m
19
Shroud Comp
Hex Flange Step Bolt 6×16.8-8×5.8
8 Ft. Lbs.
10 N.m
20
Starter Shroud
Screw ST4.0×15
10 – 11 In. Lbs.
1 N.m
21
Charging Coil
Screw Inner Six Angle M6×25
8 Ft. Lbs.
10 N.m
22
Engine Shroud
Hex Flange Bolt M6×16
8 Ft. Lbs.
10 N.m
23
Breather Valve Cover
Hex Flange Bolt M6×16
8 Ft. lbs.
10 N.m
24
Ignition Coil
Hex Flange Bolt M6×20
8 Ft. Lbs.
10 N.m
25
Regulator
Hex Flange Bolt M6×16
5 Ft. Lbs.
7 N.m
26
Oil Drain Fitting
/
20 Ft. lbs.
26 N.m
27
Oil Pump Cover
Hex Flange Bolt M6×16
8 Ft. Lbs.
10 N.m
28
Oil Screen Cover
Hex Flange Bolt M6×16
8 Ft. Lbs.
10 N.m
29
Oil Tube Plate
Hex Flange Bolt M6×16
8 Ft. lbs.
10 N.m
30
Governor Throttle
Hex Flange Bolt M6×16
8 Ft. Lbs.
10 N.m
31
Governor Arm
Nut M6
8 Ft. Lbs.
10 N.m
32
Tube Clip
Hex Flange Bolt M6×16
5 Ft. Lbs.
7 N.m
33
Connector, Oil Filter
M20
30 Ft. Lbs.
42 N.m
Engine Model
Serial Number
