- 34 -
CAUTION
POTENTIAL HAZARD
♦ Engine coolant is toxic.
WHAT CAN HAPPEN
♦ Swallowing coolant can cause poisoning.
HOW TO AVOID THE HAZARD
♦ Do not swallow
♦ Keep out of reach of children and pets.
Drain coolant when engine is cool. Coolant may be drained from the radiator by
loosening the drain cock in the right rear corner. The engine block may be
drained by removing the rear radiator hose and/or by removing the drain plugs
from the engine block.
For 23 HP Kawasaki Liquid-Cooled units: The plugs may be accessed from
the back of the engine and are located in either cylinder wall adjacent to the
main engine block. The plugs may be identified as hex head bolts with a black
finish. See Figure 8.
For 27 HP Kawasaki Liquid-Cooled units: The plug may be accessed from
the bottom left hand side of the engine. The plug may be identified as a hex
head bolt with a black finish. See Figure 8.
FIG. 8
COOLANT PLUG LOCATION
a) Re-install all drain plugs and hoses and tighten drain cock.
b) Fill radiator with a 50/50 mix of water and engine coolant (as specified in
Section 2.5.2), allowing some room (approximately 1/2”) for expansion. Add
50/50 coolant mix to overflow bottle on the left side of the engine as
required to bring the level up to the indicator line on the bottle.
27 HP KAWASAKI
23 HP KAWASAKI
