Exmark LAZER Z X Series User Manual

Specications
•Mounting:
–XandS-Series:
Hingedseatframetotiltupseat.Heldintilted
positionwithproprod.Adjustableforeand
aftonseattracks.
–E-Series:
Adjustableforeandaftonseattracks.
•SeatSafetySwitch:Integratedseatswitch.
Timedelayseatswitcheliminatesroughground
cut-outs.
HydrostaticGroundDriveSystem
•Twounitizedhydrostatictransmissions:
–X-Series52inchdeck,AllS-Series,andAll
E-Series:
◊12ccParkeraxialpistonpump
◊240ccParkergerolermotor
–X–Series60and72inchdecks:
◊16ccParkeraxialpistonpump
◊280ccParkergerolermotor
•HydraulicOilType:ExmarkPremiumHydroOil.
•HydraulicOilCapacity:52oz(1.5L)perside
•HydraulicFilter:P/N116-0164
•Speeds:
–E-Series48or52inchdecks:
◊0-8mph(12.9km/hr)forward.
◊0-4.5mph(7.2km/hr)reverse.
–AllE-Seriesexcept48or52inchdecksand
XandS–Series—12cc
◊0-10mph(16.1km/hr)forward.
◊0-5.5mph(8.9km/hr)reverse.
–XandS–Series—16cc
◊0-11.5mph(18.5km/hr)forward.
◊0-6mph(9.7km/hr)reverse.
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
TiresandWheels
X-Series:
Drive
Pneumatic(Air-Filled)
Quantity
2
Tread
TurfMaster
Size(60&72Decks)
24x12.00-12
Size(52Deck)
23x9.50-12
PlyRating
4
Pressure
13psi(90kPa)
FrontCaster
Semi-Pneumatic
DeckSize
“00”ModelsAllModels
Except“00”
Quantity
22
Tread
SmoothSmooth
Size(60&72
Decks)
13x6.50-613x6.50-6
Size(52Deck)
13x5.00-6
S-Series:
Drive
Pneumatic(Airlled)
DeckSize
48&5260&72
Quantity
22
Tread
TurfMasterTurfMaster
Size24x9.50-1224x12.00-12
PlyRating
44
Pressure
13psi(90kPa)13psi(90kPa)
21

Exmark LAZER Z X Series Specifications

General

Engine Type	V-Twin
Transmission	Hydrostatic
Engine Brand	Kawasaki
Cutting Width	60 inches
Deck Construction	Fabricated steel
Seat Type	High-back with armrests
Category	Commercial
Engine	Kawasaki
Deck Type	Fabricated
Weight	1, 495 lbs
Warranty	5-year limited
