Exmark LAZER Z X Series User Manual

Maintenance
Figure47
1.Doublenuts
8.Shutoffunit.Removejumperwirefromwire
harnessandplugconnectorintoseatswitch.
9.Removethejackstands.
10.Raisethedeckandre-installtheheightofcutpin.
11.Checkthatthemachinedoesnotcreepinneutral
withtheparkbrakesdisengaged.
MotionControlDamper
Adjustment
Thetopdampermountingboltcanbeadjustedto
obtainamoredesiredmotioncontrolleverresistance.
SeeFigure48formountingoptions.
Figure48
RHMotionControlShown
1.Torquenylocnutto200in-lb(16.7ft-lb).Boltmust
protrudepastendofnylocnutaftertorque.AT-40T orx
bitwillbenecessarytoholdthestudfromturning.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
MotionControlNeutralLock
PivotAdjustment
Theangednutcanbeadjustedtoobtainamore
desiredmotioncontrolleverresistance(Figure49).
Figure49
1.Flangednut2.Jamnut
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesired
feel.
Formoreresistance,tightentheangednut.
Forlessresistance,loosentheangednut
3.Tightenjamnut.
56

Exmark LAZER Z X Series Specifications

General

Engine Type	V-Twin
Transmission	Hydrostatic
Engine Brand	Kawasaki
Cutting Width	60 inches
Deck Construction	Fabricated steel
Seat Type	High-back with armrests
Category	Commercial
Engine	Kawasaki
Deck Type	Fabricated
Weight	1, 495 lbs
Warranty	5-year limited
