Exmark Radius X Series User Manual

Specications
•DeckLiftPedal:Footpedalthatliftsdeck.
•TransportLock:Latchingposition:Automatically
latchesatthetransportposition.
Seat
•SeatType:
–X-Series:
Deluxesuspension(adjustablespring
suspension)seatwithhighback,moldedfoam
ip-uparmrests,andintegralsafetyswitch.
–S-Series:
Deluxesuspension(adjustablespring
suspension)seatwithhighback,moldedfoam
ip-uparmrests,andintegralsafetyswitch.
–E-Series:
Standardseatwithfoampaddedseatcushion
witharmrestsandintegralsafetyswitch.
•Mounting:
–X-Series:Hingedseatframetotiltupseat.
Adjustableforeandaftonseattracks.
–S-andE-Series:Adjustableforeandafton
seattracks.
•Armrests:Moldedip-uparmrests.
•SeatSafetySwitch:Integratedseatswitch.
Timedelayseatswitcheliminatesroughground
cut-outs.
HydrostaticGroundDriveSystem
•Twounitizedhydrostatictransmissions:
–X-Series:
HydroGearZT3400
–S-Series:
◊Modelswithsidedischargedecks:
HydroGearZT3100
◊Modelswithreardischargedeck:
HydroGearZT3400
–E-Series:
◊Modelswith44,48,or52inchdecks:
HydroGearZT2800
◊Modelswith60inchdeck:
HydroGearZT3100
•HydraulicOilType:ExmarkPremiumHydroOil.
•HydraulicOilCapacity:77oz(2.3L)perside
•HydraulicFilter:P/N109-3321
•Speeds:
–X-Series:
◊Forward:0-10mph(16.1km/hr)forward.
◊Reverse:0-7mph(11.3km/hr)reverse.
–S-Series:
◊Forward:0-9mph(14.5km/hr)forward.
◊Reverse:0-6mph(9.7km/hr)reverse.
–E-Series:
44
48and52
Forward
0-7mph
(11.3km/hr)
0-8mph
(12.9km/hr)
Reverse
0-4mph
(6.4km/hr)
0-5mph
(8.0km/hr)
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
Tires&Wheels
X-Series:
Drive
Pneumatic(Airlled)
DeckSize
48&5260
Quantity
22
Tread
SuperTurfSuperTurf
Size24x9.50-1224x10.5-12
PlyRating
44
Pressure
13psi(90kPa)13psi(90kPa)
S-Series:
Drive
Pneumatic(Airlled)
DeckSize
48&5260
Quantity
22
Tread
SuperTurfSuperTurf
Size23x9.50-1223x10.50-12
PlyRating
44
Pressure
13psi(90kPa)13psi(90kPa)
14

Exmark Radius X Series Specifications

General

Brand	Exmark
Model	Radius X Series
Category	Lawn Mower
Language	English
