Exmark Radius X Series User Manual

Operation
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath.
•Useextremecautionwhenoperatinga
machineonaramp.
•EnsurethattheROPSisintheupposition
andusetheseatbeltwhenloadingor
unloadingthemachine.Ensurethatthe
ROPSwillclearthetopofanenclosedtrailer.
•Useonlyafull-widthramp;donotuse
individualrampsforeachsideofthemachine.
•Donotexceeda15-degreeanglebetweenthe
rampandthegroundorbetweentheramp
andthetrailerortruck.
•Ensurethelengthoframpisatleastfour
times(4X)aslongastheheightofthetrailer
ortruckbedtotheground.Thiswillensure
thatrampangledoesnotexceed15degrees
onatground.
•Backuprampsanddriveforwarddown
ramps.
•Avoidsuddenaccelerationordeceleration
whiledrivingthemachineonarampasthis
couldcausealossofcontroloratip-over
situation.
g027996
Figure23
1.Full-widthrampin
stowedposition
4.Rampisatleastfour
times(4X)aslongasthe
heightofthetraileror
truckbedtotheground
2.Sideviewoffull-width
rampinloadingposition
5.H=heightofthetraileror
truckbedtotheground
3.Notgreaterthan
15degrees
6.Trailer
TowingtheMachine
•Donotattachtowedequipmentexceptatthe
hitchpoint.
•Followtheattachmentmanufacturer's
recommendationforweightlimitsfortowed
equipmentandtowingonslopes.Towed
weightmustnotexceedtheweightofthe
machine,operator,andballast;otherwise
hydrostatictransmissionfailuremayoccur.Use
counterweightsorwheelweightsasdescribedin
theattachmentmanufacturer'smanual.
33

Exmark Radius X Series Specifications

General

Engine Brand	Kawasaki
Deck Construction	Fabricated
Deck Material	10-gauge steel
Engine Type	V-Twin
Drive Type	Rear-wheel drive
Turning Radius	Zero-turn
Cutting Width	60 inches
Transmission	Hydro-Gear ZT3400
Spindle Type	Aluminum
Speed	Up to 10 mph
