Maintenance
CheckShutdownCircuitChart
Note:Thestateofsystemitem(s)thatisboldisbeingcheckedineachscenario.
System
EngineParking
Brake
PTO
(Blades)
MotionControl
Levers
OperatorOutcome
Runningidle
(1/3throttle)
DisengagedDisengaged
Bothleversmoved
out(neutrallock),
bothleversmovedin,
oreitherrightorleft
levermovedin
Raiseoff
ofseat(but
don’tgetoff)
Enginemust
beginshutdown
within1second
Runningidle
(1/3throttle)
Disengaged
EngagedBothleversmovedin
Raiseoff
ofseat(but
don’tgetoff)
Enginemust
beginshutdown
within1second
Runningidle
(1/3throttle)
EngagedDisengaged
Bothleversmovedin,
oreitherrightorleft
levermovedin
Operatorin
seat
Enginemust
beginshutdown
within1second
State
of
System
61
