Exmark Radius X Series - Schematics; Electrical Schematic - Kohler Engine

Schematics
ElectricalSchematic—KohlerEngine
F01 20A
REGULATOR
F02 15A
MAIN
START RELAY
K01
30 85 86
87
RED
SW01
IGNITION SWITCH
B I
A S
R
OFF
RUN
START
P02
1 3 4 5
P02
2
BLUE/BLACK
RED/GREEN
ORANGE/RED BLUE
BLUE/RED YELLOW/BLACK
YELLOW/BLACK
YELLOW/WHITE
YELLOW/WHITE
SW02
PTO SWITCH
COM
B NC
UP
DOWN
B NO
C NO
C NC
COM COM
A NC
P10
1 2 3
P10
4 5 7 8 9
SW06
Seat OPC Switch
P04
2
P04
1
GREEN/GRAY
RED/WHITE
VIOLET/RED
RED/GREEN RED/WHITE GREEN/VIOLET
BLACK
BLACK
GREEN/YELLOW GREEN/YELLOW
EC01
HOUR METER/CONTROLLER
P06
1
MAGNETO
2
GROUND
3
START RELAY
4
FUEL SOLENOID
5
SEAT
6
B+
7
PTO
8
BRAKE
9
NEUTRAL
10
KEY A
11
NC
12
NC
BLACK
SW11
RH NEUTRAL Switch
P08
2
P08
1
SW12
LH NEUTRAL Switch
P07
2
P07
1
GREEN/BROWN
SW03
BRAKE Switch
P05
2
P05
1
CLUTCH
L01
P11
A
P11
B
BT01
TERMINAL +
TERMINAL -
BATTERY
RED
BLACK
BLACK
BLACK
P03
A B
C D
E
F
J04
1
J01
1
J05
1
J06
1
PWR DIST MODULE
P01
1 3 4 5 6 7
P01
8 9
10 11 12
2
PT01
POWER POINT
+ -
P14
1
P14
2
RED/GREEN
SP01
SP06
SP02
SP03
SP05
RED
CAP PLUG
MOD01
P09
A B
ORANGE/RED BLACK
RED/GREEN
RED/WHITE
VIOLET/RED BLACK
RED
RED/GREEN
RED/WHITE
RED/WHITE RED/WHITE RED/WHITE
ORANGE/RED
BLACK
D01
TVS DIODE
P12
B
P12
A
DC
REG
GREEN/WHITE
VIOLET BLACK
RED
ALT
ENG
GND
STARTER POWER
IGNITION
MODULES
FLYWHEEL
FUEL SOLENOID
START
REG
FUEL
GND-S/D B+
ENGINE
ENG02
RED
g229558
78
