Exmark VH3615KA - Wheel Drive System; Tires; Deck; Dimensions

- 8 -
2.6.2 Hydraulic Filter is replaceable cartridge type.
P/N 513211: 10 microns, 18 psi bypass (Summer use above 32°
F)
P/N 523541: 40 microns, 18 psi bypass (Winter use below 32°
F)
2.6.3 Speed Range: Forward 0 - 6.2 mph (10.0 km/h)
Reverse 0 - 2.2 mph (3.5 km/h)
2.7 WHEEL DRIVE SYSTEM:
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0" (25.4
mm) tapered shaft.
2.8 TIRES
Drive Front Caster
Size .........................16 x 6.50-8 ........................9 x 3.50-4
Quantity.............................2........................................ 2
Tread.......................Turf Master............................ Smooth
Ply Rating ..........................4........................................ 4
Pressure...............14 psi (97 kPa) .................22 psi (152 kPa)
2.9 DECK
2.9.1 Cutting Width:
Model 36 in. .............................................35.38 in. (89.9 cm)
Model 48 in..............................................47.24 in. (120.0 cm)
2.9.2 Discharge: Right Side
2.9.3 Blade Size:
Model 36 in. ...................18.00 in. (45.7 cm).............. Qty. 2
Model 48 in....................16.25 in. (41.3 cm).............. Qty. 3
2.9.4 Type of Drive: Manual engagement of belt with over-center lock. Belt tension
is adjustable via turnbuckle.
2.9.5 Blade Brake: When the blade engagement control is move to the disengaged
position a friction brake pad stops the rotation of the blades.
2.9.6 Deck Mounting: Bolted directly to the engine deck.
2.9.7 Cutting Height: Adjusts in 1/4” (.63 cm) increments from 1” (2.5 cm) to 4 1/4”
(10.8 cm).
2.10 DIMENSIONS
2.10.1 Overall Width: 36” 48”
Discharge chute down
46.1” 58.2”
(117.1 cm) (148.0 cm)
Discharge chute up
36.4” 48.1”
(Transport only)
(92.5 cm) (122.2 cm)
2.10.2 Overall Length: 36” 48”
Overall Length
78.0” 73.0”
(198.1 cm) (185.4 cm)
2.10.3 Curb Weight: 36” 48”
Curb Weight
∗
433 lbs. 486 lbs.
(196 kg) (220 kg)
∗ Weights will vary slightly depending on engine option.
2.10.4 Overall Height: 43.2”(109.7 cm)(all units)
2.10.5 Tread Width (to outside of tires):
36” Model....................35.6” (90.4 cm)
48” Model....................39.6” (100.6 cm
