9
Attach LP Gas Tank Blocking Bars
4
Attach Grill Body Assembly
5
Insert Leg Caps and Secure
Grill Body Assembly
6
Attach Side Shelf
7
A
1
1
2
1
2
3
A
x 3
B
x 4
C
x 8
B
Note: Please ensure to first attach screw B before putting the grill
body on the cart frame.
Note: Leave 30mm of bolt threads exposed.
B
x 4
B
C
2
Note: Please ensure to follow the labeled screw sequence in this step.
To Next Page
