Specifications
Sensor probe Ferrous Non-Ferrous
Measurement
principle
Magnetic induction Eddy current principle
Measuring range 0~1250μm
0~49.21mils
0~1250μm
0~49.21mils
Accuracy
1
(% of reading)
0~850μm: ±(3% + 1μm)
850μm ~1250μm: (±5%)
0~33.46mils: ±(3% + 0.039mils)
33.46mils ~49.21mils: (±5%)
0~850μm: ±(3% + 1.5μm)
850μm ~1250μm: (±5%)
0~33.46mils: ±(3% + 0.059mils)
33.46mils ~49.21mils: (±5%)
Resolution 0~50μm: (0.1μm)
50μm ~850μm: (1μm)
850μm ~1250μm: (0.01μm)
0~1.968mils: (0.001mils)
1.968mils~33.46mil:s (0.01mils)
33.46mils~49.21mils: (0.1mils)
0~50μm: (0.1μm)
50μm ~850μm: (1μm)
850μm ~1250μm: (0.01μm)
0~1.968mils: (0.001mils)
1.968mils~33.46mils: (0.01mils)
33.46mils~49.21mils: (0.1mils)
Min. curvature
radius
1.5mm 3mm
Diameter of Min.
area
7mm 5mm
Basic critical
thickness
0.5mm 0.3mm
Industrial standards Conforms to GB/T 4956-1985, GB/T 4957-1985, JB/T 8393-1996,
JJG 889-95, and JJG 818-93
Operating
Temperature
0°C~40°C (32°F~104°F)
Operating Relative
Humidity (R.H.)
20%~90% Relative Humidity
Dimensions 110 x 50 x 23mm (4.3 x 2.0 x 1.0”)
Weight 100g. (3.9 oz)
1. Accuracy statement applies on a flat surface, with a zero and a calibration performed
near the thickness of the film to be measured, with an identical base metal and with
the meter stabilized at ambient temperature. The accuracy of the reference films or
any reference standards should be added to measurement results.
