Extech Instruments EX210 User Manual

EX210_EX210T-en-US_v1.5 9/15
5
Controls and Jacks
1. IR Thermometer
2. Laser Pointer
3. 2000 count LCD
4. MAX button
5. MODE button
6. FUNCTION switch
7. mA, µA and 10A input jacks
8. IR Thermometer button
9. HOLD button
10. RANGE button
11. Positive input jack
12. COM input jack
Note: Tilt stand, test lead holders, and battery compartment are on rear of unit.
Symbols and Enunciators
Continuity
Diode test
µ micro (10
-6
) (amps)
m milli (10
-3
) (volts, amps)
A Amps
k kilo (10
3
) (ohms)
M mega (10
6
) (ohms)
Ohms
V Volts
AC Alternating current
DC Direct current
ºF Degrees Fahrenheit
ºC Degrees Centigrade
MAX Maximum
AUTO Autoranging
HOLD Display hold
SCAN IR temperature in progress
