EX330-EU-ENG – V4.2 1/08
18
Resistance
400Ω 0.1Ω ±(1.2% reading + 4 digits)
4kΩ 1Ω
±(1.2% reading + 2 digits)
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ
40MΩ 0.01MΩ ±(2.0% reading + 3 digits)
Capacitance
4nF 0.001nF
±(3.5% reading + 40 digits)
40nF 0.01nF
400nF 0.1nF
±(2.5% reading + 4 digits)
4μF 0.001μF
±(3.5% reading + 4 digits)
40μF 0.01μF
200μF 0.1μF ±(3.5% reading + 10 digits)
Frequency
5.000Hz 0.001Hz
±(0.1% reading + 1 digits)
50.00Hz 0.01Hz
500.0 Hz 0.1Hz
5.000kHz 0.001kHz
50.00kHz 0.01kHz
500.0kHz 0.001MHz
5.00MHz 0.01MHz
10.00MHz 0.01MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min
@ 20% to 80% duty cycle and > 100kHz.
Duty Cycle 0.1 to 99.9% 0.1%
±(1.2% reading + 2 digits)
For duty cycle the pulse width range is 100µs - 100ms (Frequency: 5Hz to
150kHz)
Temp (type-K)
-4 to 1382°F 1°F ±(3.0% reading + 8 digits)
(probe accuracy not included)
-20 to 750°C 1°C
NOTES:
Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
Accuracy is stated at 65
o
F to 83
o
F (18
o
C to 28
o
C) and less than 75% RH.
UL LISTED
The UL mark does not indicate that this product has been evaluated for the
accuracy of its readings.
