EX520-EU_ENG V2.3 1/08
14
Function Range Resolution Accuracy
Resistance
600Ω 0.1Ω
±(0.3% reading + 4 digits)
6kΩ 0.001kΩ
60kΩ 0.01kΩ
600kΩ 0.1kΩ
6MΩ 0.001MΩ
40MΩ 0.01MΩ ±(0.3% reading + 20 digits)
Capacitance 60nF 0.01nF
±(3.5% reading + 4 digits)
600nF 0.1nF
6μF 0.001μF
60μF 0.01μF
600μF 0.1μF
1000μF 1μF ±(5% reading + 5 digits)
Frequency
(electronic)
9.999Hz 0.001Hz
±(0.1% reading + 1 digits)
99.99Hz 0.01Hz
999.9Hz 0.1Hz
9.999kHz 0.001kHz
99.99kHz 0.01kHz
999.9kHz 0.1kHz
9.999MHz 0.001MHz
40MHz 0.01MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @
20% to 80% duty cycle and > 100kHz
.
Frequency
(electrical)
10.00-400Hz 0.01Hz
±(0.5% reading)
Sensitivity: 15Vrms
Duty Cycle 0.1 to 99.9% 0.1%
±(1.2% reading + 2 digits)
Pulse width: 100µs - 100ms, Frequency: 5Hz to 150kHz
Temp
(type-K)
-50 to 1382°F 1°F ±(3.0% reading + 5°C/9°F)
(probe accuracy not included)
-45 to 750°C 1°C
Note: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital converter.
