Inductance ( Lp/Ls ) : D
≦
0.1
Range Accuracy Accuracy Remark
100Hz/120Hz 1000Hz
20uH ± (1% + 5d ) ± (1% + 5d ) After calibration
200uH ± (1% + 5d ) ± (1% + 5d ) After calibration
2000uH ± (0.8% + 5d ) ± (0.8% + 5d )
20mH ± (0.5% + 5d ) ± (0.5% + 5d )
200mH ± (0.5% + 5d ) ± (0.5% + 5d )
2000mH ± (0.5% + 5d ) ± (0.5% + 5d )
20H ± (0.5% + 5d ) ± (0.5% + 5d )
200H ± (0.5% + 5d ) ± (0.8% + 5d ) After calibration
2000H ± (1% + 5d ) ----------------------- After calibration
Range Accuracy Accuracy Remark
10kHz 100khz
20uH ± (1% + 5d ) ± (1% + 5d ) After calibration
200uH ± (0.8% + 5d ) ± (0.8% + 5d ) After calibration
2000uH ± (0.5% + 5d ) ± (0.5% + 5d )
20mH ± (0.5% + 5d ) ± (0.5% + 5d )
200mH ± (0.5% + 5d ) -----------------------
2000mH ± (0.5% + 5d ) -----------------------
Note:
* If the impedance is larger than 10k, Lp is shown on the display.
* If the impedance is less than 10k, Ls is shown on the display.
