Extech Instruments lcr200 User Manual

9 LCR200-EU-EN V1.5
11/13
Range
Accuracy Accuracy
10kHz 100kHz
20  ± ( 1.0%rdg + 5digits ) ± ( 2.0%rdg + 5digits ) After calibration
200  ± ( 0.5%rdg + 5digits) ± ( 0.5%rdg + 5digits )
2k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
20k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
200k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
2M  ± ( 1%rdg + 5digits ) ± ( 2.0%rdg + 5digits ) After calibration
20M  ± ( 2.0%rdg + 5digits ) --------------------- After calibration
* If the impedance is larger than 10k, Rp is shown on the display
.
* If the impedance is less than 10k, Rs is shown on the display.
Capacitance ( Cp/Cs ) : D ≦ 0.1
Range Accuracy Accuracy Remark
100Hz/120Hz 1000Hz
20pF ± (2.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
200pF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
2000pF ± (0.8%rdg + 5digits ) ± (0.8%rdg + 5digits ) After calibration
20nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
200nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
2000nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
20uF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
200uF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits ) After calibration
2000uF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
20mF ± (2.0%rdg + 5digits ) ------------------------ After calibration
Capacitance ( Cp/Cs ) : D ≦ 0.1
Range Accuracy Accuracy Remark
10kHz 100kHz
20pF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
200pF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits ) After calibration
2000pF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits) After calibration
20nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits )
200nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5d igits)
2000nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits )
20uF ± (0.8%rdg + 5digits ) ± (0.8%rdg+ 5digits )
200uF ± (1.0%rdg + 5digits ) -------------------------- After calibration
* If the impedance is larger than 10k, Cp is shown on the display
.
* If the impedance is less than 10k, Cs is shown on the display.
