Description
MeterDescription
1. ProbeConnection
2. LCDDisplay
3. HOLDButton
4. POWERButton
5. RECButton
6. ZEROButton
7. MODEDC/AC/SETButton
8. Tilt‐Standandbatterycompartmentonrear
9. ResetButton
10. DC9VPowerAdapterjack












ProbeDescription
1. ProbeSensingHead
2. ProbeHandle
3. Probecable
4. ProbeHeadCover









1
2
3
Fig. 1 – Meter Description
Fig. 2 – Probe Description
