123

DisplayDescription

1. NorthNorSouthSindication

2. Unitofmeasure

(GforGauseormTformilliTesla)

3. ACorDCfieldandresolutioninformation

4. Magneticreading



ButtonDescription

1. POWERButton:PressandholdtopowerthemeterONorOFF

2. HOLD Button: Short press to freeze displayed reading (HOLD icon will appear); another

shortpresstoreturntonormaloperation

3. RECButton:ShortpresstostartrecordingMAXandMINreadings.Additionalshortpresses

willscroll

throughthesavedMAXandMINreadings.Pressandholdtoexitthismode

4. MODE DC/AC/SET Button: Short presses to scroll through the available units of measure

andNorth/Southmodes.LongpresstoaccesstheUserSettingsmenu

5. ZEROButton:Shortpresstozerothedisplaybeforetaking

areading

Reset Button (right side of meter; not pictured below): Press to restore the meter to factory

default conditions. If the meter becomes unresponsive use the reset button to restore the

meter.



Fig. 3 – Display Description

Fig. 4 – Button Description

Extech Instruments MF100 User Manual
