Extech Instruments RHT30 - PDF Logger Configuration Tool

5RHT30_TH30‐en‐GB_V1.0(11/16)
PDFLoggerConfigurationTool
ConnectthedataloggertoPCUSBport.ThePCwillprompttoviewfiles.Openthe‘PDF
LoggerConfigurationTool’fromthelistofavailablefiles.RefertotheOperation
Sectionforadditionaldetailsonthistool:




1. CONVERTTOEXCEL:Createaspreadsheetreportoftheloggeddata
2. CONVERTTOPDF:CreateaPDFreportandatrendgraphoftheloggeddata
3. CONFIGURATION:Clicktoconfigurethelogger
4. LANGUAGESELECTION
5. SAMPLINGRATE:Dataloggerrecordinginterval
6. STARTDELAY:Delayperiodfrom
whenSTARTispressedanddataloggingbegins
7. TEMP.UNIT:Temperatureunitselection(
o
C/
o
F)
8. PASSWORD:Selecta16‐characterpasswordfortamperprotection
9. COMPANYNAME:20‐Characteruserlabelforinclusioninloggingreport
10. SAVE:PressSAVEtoconfirmtheconfiguration
11. MANUAL:OpenthesuppliedPDFUserManual
12. CANCEL:Aborttheconfiguration
13. ALARMLIMIT:SelecttheRH%and
Temperaturelow/highalarmlimits.Notethat
fortheTH30,RH%isreplacedbyexternaltemperatureprobealarmlimit
14. ALARMDELAY:Dataloggerwillignorealarmsfortheprogrammedperiodoftime
15. ALARMTYPE:SelectAlarmmode
