Extech Instruments RHT30 User Manual

6RHT30_TH30‐en‐GB_V1.0(11/16)
Operation
NOTES:
1.AdobeReader®softwareisrequired.
2.EnsuretheloggerisatroomtemperaturebeforeinsertingitintoaPCport.
3.Theexecutablefileforprogrammingisnamed“PDFLoggerConfigurationTool”.
4.Adataloggingsessioncannotstartuntilthedataloggerisproperlyconfigured.
ConfiguringtheTH30andRHT30foraDataloggingsession
Atanytimebeforeloggingisstarted,theloggercanbeprogrammedandre‐
programmed.Thepreviousloggingsessionwillbedeletedonceanewsessionis
started.
1. ConnectthedataloggertoaPCviatheUSBport.TheloggerwillswitchON
automatically.Notethatashortpress
ofthepowerbutton willalsopower
thelogger.
2. TheLEDwillglowgreenwhilea
connectionwithcomputerisbeing
established.
3. AnAutoPlaypromptwillappearonthePC
whencommunicationisestablished.
4. Clickon‘Openfoldertoviewfiles’tosee
theavailablefiles.
Opentheprogram"PDFLogger
ConfigurationTool.exe".
5. ThedefaultlanguageisEnglish;selectGerman,French,Italian,Spanish,or
Portugueseasdesired.Thegeneratedloggingreportformatwillmatchthe
languageselected.
6. ToreviewtheUserManual,click‘Manual’toopentheUserManualPDFfile.
7. Theparametersneededtoconfigurethedataloggerfor
loggingaredefined
below.Refertotheearlierscreenshotofthe‘PDFLoggerConfigurationTool’
windowforreference:
 DatalogSamplingRate
Selectthedataloggingsamplingrate(recordinginterval)from30seconds~
120minutes.Thedefaultsettingis30seconds.
 DatalogStartDelay
Selectaperiodof
timethatmustelapsebeforerecordingcanbeginafterthe
Start/Stopbutton
ispressed(selectfrom0minto24hours).Thedefault
settingis0minutes.
 TemperatureUnitofMeasurement
 Selectthetemperatureunit°Cor°F.
