11 SDL200-EN V2.3 07/13
Specifications
General Specifications
Display Backlit LCD; LCD size: 2 x 1.5”(52 x 38mm)
Status indicators Over-range (----) and low battery
Measurement Channels T1, T2, T3, T4, and T1-T2
Sensor types Thermocouple types: K, J, T, E, R, and S
RTD type: platinum 100 ohm (Complies with 0.00385 alpha
coefficient meeting DIN IEC 751)
Measurement Units °C / °F
Offset Adjustment Available for one (1) thermocouple and two (2) RTD inputs
Input Linearity Sensor curves are stored in meter’s CPU
Datalogger Sampling Rate AUTO LOGGING: 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800,
3600 seconds. Note that a one (1) second sampling rate
can cause some data loss on slower computers
MANUAL LOGGING: Set the sampling rate to ‘0’
Memory Card SD memory card; 1G to 16GB size
Temperature Compensation Auto temperature compensation for all thermocouple types
Display update rate Approx. 1 second.
Data Output RS-232 / USB PC computer interface
Operating Temperature 32 to 122°F (0 to 50°C)
Operating Humidity 85% R.H. max.
Auto Power OFF After 10 minutes of inactivity (can be disabled)
Power Supply Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
Power Consumption Normal operation (backlight & datalogger OFF): approx. 9.7mA dc
With backlight OFF and datalogger ON: approx. 30mA dc
With backlight ON and datalogger OFF: approx. 17mA dc
Weight 0.62 lbs (280g) meter only
Dimensions Main instrument: 7.1 x 2.9 x 1.9”(182 x 73 x 47.5mm)
Electrical Specifications
(ambient temperature 23
°
C ± 5
°
C)
Pt 100 ohm RTD Input
(0.00385 alpha coefficient meeting DIN IEC 751)
Resolution Range Accuracy
0.1
°
C
-199.9 to 850.0
°
C
± (0.4 % + 1
°
C)
0.1
°
F
-327.0 to 999.9
°
F
± (0.4 % + 1.8
°
F)
1
°
F
1000 to 1562
°
F
± (0.4 % + 2
°
F)
