Extech Instruments SL120 - Meter Description

Version 1.2 9/05
3
1
2
3
4
5
7
8
6
9
30-80
LIMIT
80-130
60-110
1
2
3
4
5
6
Meter Description
1. Microphone
2. Over Limit Display
3. Bargraph
4. dB display
5. OFF/ON/AUTO switch
6. Clock display
7. Max level display with time stamp
8. Set limit
9. MAX RESET button
Rear Panel
1. Range select switch
2. Time set buttons
3. Limit set buttons
4. Calibration adjustment
5. A/C select button
6. F/S select button
