Extech Instruments TM500 User Manual

2 TM500-EU-EN v1.1 12/13
Introduction
CongratulationsonyourpurchaseoftheExtechTM500Thermometer,anSDLoggerSeries
meter.
Thismeterdisplaysandstorestemperaturereadingsfromuptotwelve(12)TypeK,J,T,R,E,orS
thermocoupletemperatureprobes.LoggeddatareadingsarestoredonanSDcardfortransfertoa
PC.Inaddition,anRS232portallowsdatastreamingtoaPC.Thismeterisshippedfullytestedand
calibratedand,withproperuse,willprovideyearsofreliableservice.PleasevisittheExtech
InstrumentswebsitetocheckforthelatestversionofthisUserGuide.
MeterDescription
1. Thermocoupleinputs
2. DCpoweradapter,SDmemoryslot,andPCinterfacejack
3. PowerON‐OFF
andBacklightkey
4. HOLDandNEXTkey
5. PowerON‐OFF
andESCkey
6. RECandENTER
7. TYPE▲key(K,J,T,R,E,orS)
8. LOGGER(Offset)key
9. SET(TimeCheck)key
10. PAGE▼key(DisplayT1‐8orT9‐12)
LOG
TYPE PAGE
SET
ESC
HOLD
NEXT
REC
ENTER
12-Channel Thermocouple Datalogger
TM500
VIEW SAMPLE
RATE
VIEW TIME
OFFSET
F
CH8
CH7
CH6
CH5
CH4
CH3
CH2
CH1
K
1
2
3
4
5
6
7
8
9
10
