VT30 V2.1 10/06
6
Specifications
LCD display 1999 counts (3-1/2 digits) with bargraph and backlight
Resolution 1 Volt
AC Voltage range 0 to 480V
ACV frequency range 50/60Hz
DC Voltage range 0 to 690V
Accuracy ACV ±(1.5%rdg + 5d); DCV ±(1.0%rdg + 3d)
Range selection Automatic
Max measuring current ≤1.0mA (400VAC); ≤1.5mA (690VDC)
Response time Updates 2-3 times/sec
Input Impedance 1MΩ (approx)
Continuity test Range 0 to 200kΩ, guaranteed on < 50kΩ; <5µA test
current
Overvoltage protection 480VAC/690VDC
Low impedance test 12-250VAC/DC; impedance <6kΩ;
LCD enable input voltage >4.5V AC/DC
Operation time: 5s<250V AC/DC
Power supply 2 x “AAA” 1.5V alkaline batteries
Battery life Approx. 8 hours continuous use typical
Operating Temperature 14 to 131
o
F (-10 to 55
o
C)
Storage Temperature -22 to 140
o
F (-30 to 60
o
C)
Operating Humidity 10 to 85% RH (non-condensing)
Safety This meter is intended for origin of installation use and
protected, against the users, by double insulation per
EN61243-3 and IEC61243-3 to Category IV 600V and
Category III 1000V; Pollution Degree 2.
Approvals CE, IP64
Dimensions 9.4 x 3 x 1.6” (240 x 78 x 40mm)
Weight 9.2oz (260g)
