CHAPTER 27
PAGE 26
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
27-31-00 MAINTENANCE PRACTICES
27-31-01 Elevator Removal/Installation
Before the removal of the elevator, the vertical stabilizer
has to be disassembled.
1 Remove the respective access panels.
2 Remove the rudder per Chapter 27-21-01
3 Remove the vertical stabilizer per Chapter 55-21-01.
4 Loosen the bowden cables from the trim tab. If a re-
placement is necessary order new cable.
5 Disconnect the elevator actuator arm from the push-
pull rod.
6 Loosen the hinge bolts and the ground bonding leads
and remove the bolts.
7 Install in reverse sequence of removal. Observe the sec-
ond Note of Chapter 27-01-00.
27-31-02 Trim Tab Removal/Installation
1 Loosen bowden cables. If a replacement is necessary
order new cable.
2 Disconnect the safety cotter pin and remove the hinge
pin.
3 Install in reverse sequence of removal and use a new
cotter pin.
27-31-03 Elevator Rigging
I M P O R T A N T Before beginning any adjustments, inspect control rods,
levers and hinges for signs of wear or damage and check
if control rod lengths correspond with the measurements
given in Chapter 27-00-02. Replace parts and correct
lengths if necessary per Chapter 27-01-06.
PAGE DATE: 15. December 1999
