CHAPTER 31
PAGE 6
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
INSTRUMENT AND CONTROL PANELS
31-10-02 Front Instrument Panel
The front instrument panel (1, Figure 2) incorporates shock
mounts and carries an altimeter (2) and an air speed
indicator (3).
Front Instrument Panel
Figure 2
