Chapter10
LUMINOUS INDICATORS
Signals
Description Explanation
Indicator light
It indicates the Weekly programmer
function
It is on/o when the Weekly programmer function is activated/
deactivated.
For all settings relative to the following function see the “Weekly
programmer” function.
Indicator between the real
functioning power and the power
set-point
The indicator  ashes when the real functioning power is di erent
to that set.
The indicator has a  xed light when the real functioning power is
the same as that set.
Not used Not used
It indicates deactivation of the
ign-plug
It is o /on when the electrode is activated/deactivated.
To restore the functioning of the component, contact an authorised
technician.
It indicates functioning of the
fumes motor
It is on/o when the fumes exhaust motor is activated/deactivated.
It indicates pump functioning It is o /on when the pump is activated/deactivated.
It indicates functioning of the
pellet feed motor
It is on/o when the pellet feed motor is activated/deactivated.
During normal functioning the following indicator switches on
 ashing.
Not used Not used
Indicates the status of OUT3 and
OUT4
If on it indicates the functioning of both outputs (OUT3 and OUT4).
If it  ashes quickly (2  ashes per second) it indicates functioning of
output OUT4.
If it  ashes slowly (1  ash per second) it indicates functioning of
output OUT3.
If o it indicates that the 2 outputs are o .
Indicates the automatic cleaning
status of the pot
The indicator  ashes/is  xed when the automatic cleaning of the
pot is activated/deactivated.
Indicates the receipt of the signal
from the remote control
Is switched on during communication between remote control and
boiler.
