AP-7532 Access Point Installation Guide 5
*
* This antenna is for indoor placement only.
AP-7532 Dual Band 2.4 GHz / 5 GHz Antennas - EMEA
An external antenna AP-7532 supports the following dual band antenna options for the
EMEA:
AP-7532 Internal Antenna Model
An AP-7532 internal antenna Access Point supports the following dual band antenna:
Note
Per FCC requirement, the use of the Access Point on UNII-1 of 5GHz band requires
installers to input antenna elevation gain during configuration if the AP placement is
for outdoor coverage.
Part Number
Antenna
Type
2.4 GHZ
Gain (dBi)
5 GHZ
Gain (dBi)
Elevation Gain for
outdoor
placement (dBi
)
ML-2452-APA2-01 Dipole 3.17 4.85 na*
ML-2452-HPA5-036 Dipole 3 5 na*
ML-2452-APAG2A1-01 Dipole 2.7 1.7 na*
ML-2452-PNL9M3-N36 Polarized-
Panel
11 10.7 7.3
ML-2452-PNA5-01R Panel 5.5 6 5.2
ML-2452-PTA3M3-036 Patch 5 4 na*
ML-2452-VMM5M3-
N72
Patch 4.5 5.4 2.9
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi)
ML-2452-APA2-01 Dipole 3.17 4.85
ML-2452-HPA5-036 Dipole 3 5
ML-2452-APAG2A1-01 Dipole 2.7 1.7
ML-2452-HPAG4A6-01 Dipole 4 7.3
ML-2452-HPA6-01 Dipole 5.3 6.1
ML-2452-PNL6M3-N36 Polarized-Panel 6 6
ML-2452-PNA5-01R Panel 5.5 6
ML-2452-PTA3M3-036 Patch 5 4
ML-2452-VMM5M3-N72 Patch 4.5 5.4
