Power Supplies
The non-PoE X435 Series switches contain internal, non-FRU power supplies. X435-8P-2T-W is
powered via the front PoE/PD ports.
Operating Temperatures
The 8-port X435 switch models support an operating range from 0°C to 40°C. The 24-port models
support an operating range from 0°C to 45°C. Temperature restrictions apply for some models at high
altitudes. See each individual model's description for more detail.
ExtremeSwitching X435-8T-4S Switch Features
The front panel of the X435-8T-4S switch includes:
• Eight 10/100/1000BASE-T ports that provide 8Gbps of high-density copper connectivity.
• Four unpopulated 1/2.5G SFP ports that support
fiber connectivity
Note
2.5Gb uplink support is a future capability
• One RJ-45 console port
• One USB A port
• LEDs to indicate port status and switch operating conditions
For a description of the LEDs and their operation, see ExtremeSwitching X435 Series Switch LEDs on
page 28
Figure 1: X435-8T-4S Switch Front Panel
1 = System LEDs 3 = RJ-45 console port 5 = 1/2.5G SFP ports*
2 = USB A port 4 = 10/100/1000BASE-T ports
Note
*2.5Gb uplink support is a future capability
The rear panel of the X435-8T-4S switch includes:
• AC power input socket
The internal AC power supply operates from 100VAC to 240VAC.
ExtremeSwitching Switches
Power Supplies
ExtremeSwitching Hardware Installation Guide 23
