AVT 200HD Tuner • Remote Configuration and Control 50
Command
ASCII Command
(Host to Tuner)
Response
(Tuner to Host)
Additional Description
Video Output (continued)
Closed Captioning (continued)
View CC text ll
E
O FSCC
} X1*]
Show the selected font fill.
Select CC background color
E
K
X1&
FSCC
}
FsccK
X1&]
Select background color
X1&
for
the closed caption. For
X1&
:
0 = white
1 = black (default)
2 = red
3 = green
4 = blue
5 = yellow
6 = magenta
7 = cyan
View CC background color
E
K FSCC
} X1&]
Show the selected background
color.
Select CC background fill
E
T
X1*
FSCC
}
FsccT
X1*]
Select type of fill
X1*
for the
closed caption background. For
X1*
:
0 = solid (default)
1 = transparent
2 = translucent
3 = flashing
View CC background ll
E
T FSCC
} X1*]
Show the selected background
fill.
Select CC text edge type
E
E
X2*
FSCC
}
FsccE
X2*]
Select text edge type
X2*
for the
closed caption. For
X2*
:
0 = none (default)
1 = raised
2 = recessed
3 = uniform
4 = left shadow
5 = right shadow
View CC text edge type
E
E FSCC
} X2*]
Show the selected edge type.
Select CC edge color
E
D
X1&
FSCC
}
FsccD
X1&]
Select edge color
X1&
for the
closed caption. For
X1&
:
0 = white
1 = black (default)
2 = red
3 = green
4 = blue
5 = yellow
6 = magenta
7 = cyan
View CC edge color
E
D FSCC
} X1&]
Show the selected edge color.
Audio Output
Set digital audio output
format
EX(
AFMT
}
Afmt
X(]
Select digital output type
X(
.
For
X(
:
1 = AC-3 (Dolby digital)
2 = PCM
View digital audio output
format
E
AFMT
} X(]
Show the selected digital audio
output format.
