SIS Command and Response Table for Output-Endpoint-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit to Endpoint)
Response
(Endpoint to Unit to Host)
Additional Description
XTP SR HDMI scaler specific commands (continued)
Relay controls
Turn on an endpoint relay
EX@
*
X4)
*1RELY
}
Rely
X@
*
X4)
*1
]
Turn on relay
X4)
in output
X@
.
Turn off an endpoint relay
EX@
*
X4)
*0RELY
}
Rely
X@
*
X4)
*0
]
Turn off relay
X4)
in output
X@
.
Toggle an endpoint relay
EX@
*
X4)
*2RELY
}
Rely
X@
*
X4)
*
X4@]
Toggle (on-to-off or off-to-on) relay
X4)
in output
X@
.
Pulse an endpoint relay
EX@
*
X4)
*3*
X4!
RELY
}
Rely
X@
*
X4)
*3
]
Turn on relay
X4)
in output
X@
for an
interval defined as
X4!
. Each step of
X4!
is 16 ms.
Example:
E
1*2*3*45RELY
}
Rely1*2*3
]
Turn on relay 2 in output endpoint 1 for
720 ms
(0.72 sec,
X4!
= 45 * 16 ms = 720 ms).
View an endpoint relay status
EX@
*
X4)
RELY
} X4@]
On or off.
View video and audio mutes
View output mutes
E
VM
} X3(
1
X3(
2
...
X3(
n
]
Each
X3(
response is the mute status of
an output, starting from 1.
n = is 16, 32, or 64.
Example :
(XTP II CrossPoint 3200)
E
VM
}
Audio is muted on outputs 2 and 3,
video on output 5, and video and audio
on output 26. All other outputs are
unmuted.
02201000000000000000000003000000
]
NOTE: X@ = Output number 01 – 16, 32, or 64
X3( = Video and audio mute status 0 = No mutes 4 = Analog audio mute
1 = Video mute 5 = Video and analog audio mute
2 = Digital audio mute 6 = Digital and analog audio mute
3 = Video and digital audio mute 7 = Video, digital audio, and analog audio mute
X4)
= Relay on endpoint 1 or 2
X4!
= Pulse duration 0 through 65535 (each step = 16 ms, see the example above)
X4@
= Relay status
0
= Off
1
= On
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 109
