USER MANUAL
H.264 REAL TIME DVR
78
5-4. Product Specification
MODEL 4ch 960H DVR 8ch 960H DVR 16ch 960H DVR
OPERATING SYSTEM Embedded Linux
COMPRESSION H.264 HARDWARE CODEC
MULTIPLEX FUNCTION Live, Record, Backup and Network at the same time
RECORDING RESOLUTION
960H, D1, Half D1, CIF
RECORDING SPEED
120fps(NTSC), 100fps(PAL)
at 960H
240fps(NTSC), 200fps(PAL)
at 960H
480fps(NTSC), 400fps(PAL)
at 960H
VIDEO INPUT 4 BNC Composite 8 BNC Composite 16 BNC Composite
VIDEO OUTPUT 1 HDMI, 1 VGA, 1 BNC
AUDIO INPUT/OUTPUT 2ch / 1ch 2ch / 1ch 16ch / 1ch
SENSOR INPUT / ALARM
OUTPUT
Optional item - 4 line(NC/NO selectable)/ 1 line(NC/NO selectable)
Display Mode 1/4/Auto sequential 1/4/9/Auto 1/4/9/13/16/Auto
BACKUP MEDIA USB storage, Network
STORAGE MEDIA 1 SATA HDD 2 SATA HDD 2 SATA HDD
RECORDING MODE Continuous, Alarm, Motion, Instant panic
OPERATION CONTROL Mouse and Remote controller
COMMUNICATION PORT RS-485
NETWORK LAN(Ethernet RJ-45, 10/100 base), DDNS, TCP/IP
LAN(Ethernet RJ-45,
10/100/1000 base), DDNS,
TCP/IP
SIZE(mm) 278(W)x215(D)x48(H) 320(W)x251(D)x48(H) 375(W)x272(D)x50(H)
WEIGHT 1.3Kg 2.2Kg 2.6Kg
POWER DC12V/3A Adaptor DC12V/3A Adaptor DC12V/4A Adaptor
POWER CONSUMPTION Max. 12W Max. 18W Max. 25W
OPERATING
TEMPERATURE
0°C ~ 40°C
OPERATING HUMIDITY 0% RH ~ 80% RH
※ The detail and specification of this product can partially change for quality improvement.
