Ezgo SHUTTLE 4 - Vehicle Dimensions and Incline Specifications

Page 26
Owner’s Manual and Service Guide
*(1(5$/63(&,),&$7,216
Fig. 38 Vehicle Dimensions and Incline Specifications
RECOMMENDED
MAX RAMP GRADE
25% or 14˚ MAX
RECOMMENDED MAX SIDE TILT
25% or 14˚ MAX
Front
33.5 in. (85 cm)
Rear
38 in. (97 cm)
49 in.
(123 cm)
67 in.
(170 cm)
