Ezviz BC1C User Manual

2
Setup
1. Power-on
In the shutdown state, hold the RESET button for 2 seconds to power on.
If the camera is out of battery, connect it to power outlet with the power adapter
for charging (5V 2A).
• It is recommended to use the power adapter and power cable included in the package.
• Remove the camera from the wall before charging.
• Please do not charge the camera when the temperature exceeds 45 degrees or below
0 degrees.
• It is not allowed to charge the camera with power adapter outdoors.
• When charging, the camera will be automatically turned on.
2. Connect to the Internet
1. Get the EZVIZ App
- Connect your mobile phone to Wi-Fi (suggested).
- Download and install the EZVIZ app by searching “EZVIZ” in the App Store or
Google Play
TM
.
- Launch the app and register an EZVIZ user account.
EZVIZ App
If you have already used the app, please make sure that it is the latest version. To find
out if an update is available, go to the app store and search for EZVIZ.
2. Add camera to EZVIZ
- Press and hold the RESET button on the camera for 5 seconds. The LED
indicatorwillfastashblue.
- Log in to your account using the EZVIZ app.
- On the Home screen, tap “+” on the upper-right corner to go to the Scan QR
Code interface.
- Scan the QR code on the Quick Start Guide cover or on the body of the camera.

Ezviz BC1C Specifications

General

Mounting kit	Yes
Number of cameras	1
Type	IP security camera
Operating frequency	2400 - 2483.5 MHz
Placement supported	Outdoor
Connectivity technology	Wireless
Built-in HDD	No
Flash memory	32768 MB
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UL ECOLOGO, WEEE
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, Grey
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP66
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Minimum illumination	0.2 lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Optical sensor size	1/2.8 \
Battery capacity	7800 mAh
DC output current	2 A
DC output voltage	5
Power source type	Battery
Battery technology	Lithium
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Fixed focal length	2.8 mm
LED type	IR
Night vision distance	10 m
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Supported graphics resolutions	1920 x 1080 (HD 1080)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	72 Mbit/s

Weight and Dimensions

Depth	62.8 mm
Width	104.76 mm
Weight	365 g
